JST VH 系列 母 印刷电路板连接器触点 BVH-21T-P1.1, 镀锡 磷铜触芯, 20mΩ最大接触电阻

JST VH Series Crimp Contacts

These VH Series of Wire to Board, 3.96 mm pitch, Through Hole Connectors from JST are suitable for use in a signal, power supply or output circuit applications. The compact size and large capacity coupled with secure contact and mounting are the special features of these VH Series of Wire to Board, 3.96 mm pitch, Through Hole Connectors.

Stock Number 762-0698 wire size 20-16 AWG (0.5-1.25 mm2) Loose Crimp Contacts
Stock Number 762-0692 wire size 20-16 AWG (0.5-1.25 mm2) Reeled Crimp Contacts
Stock Number 762-0702 wire size 20-18 AWG (0.33-0.83 mm2) Reeled Crimp Contacts

注

For VH Series Crimp Housings see stock number 762-0737 typical.
The JST Part Number BVH-41T-P1.1 for loose contacts does not appear on the Datasheet only the reeled version SVH-41T-P1.1 .
