851 02E 2041P50,160-0651,Souriau 41路 面板安装 连接器 卡口耦合 插座 851 02E 2041P50, 公触芯, 外壳尺寸20, MIL-DTL-26482 ,Souriau
Solder contacts ? 1 mm for 24 → 18 AWG cable (cross-section = 0.21 → 0.93 mm2).
The 1412 model also features 4 size 16 contacts (? 1.6 mm) for 18 → 14 AWG cable (cross-section = 0.93 → 1.91 mm2).
| 4 flange mounting holes ? 3.13 mm |
| ref. | Stock | no. of contacts | dimensions | |
| Souriau | no. | ? 1 (mm) | ? 1.6 (mm) | flange (mm) |
| 851 02 E 83A P 50 | 194-2006 | 3 | - | 20.99 |
| 851 02 E 833 P 50 | 195-3179 | 3 | - | 20.99 |
| 851 02 E 106 P 50 | 195-3157 | 6 | - | 24.19 |
| 851 02 E 1210 P 50 | 195-3141 | 10 | - | 26.54 |
| 851 02 E 1412 P 50 | 129-8725 | 8 | 4 | 28.89 |
| 851 02 E 1419 P 50 | 195-3135 | 19 | - | 28.89 |
| 851 02 E 1626 P 50 | 129-8371 | 26 | - | 31.29 |
| 851 02 E 1832 P 50 | 195-3129 | 32 | - | 33.69 |
| 851 02 E 2041 P 50 | 160-0651 | 41 | - | 36.89 |
| 851 02 E 2255 P 50 | 194-2012 | 55 | - | 39.99 |
| ref. | mounting | excess | ? front | ? panel hole |
| Souriau | (mm) | at front (mm) | (mm) | (mm) |
| 851 02 E 83A P 50 | 15.09 | 11.70 | 12.03 | 15.55 |
| 851 02 E 833 P 50 | 15.09 | 11.70 | 12.03 | 15.55 |
| 851 02 E 106 P 50 | 18.26 | 11.70 | 15.01 | 18.80 |
| 851 02 E 1210 P 50 | 20.62 | 11.70 | 19.07 | 22.15 |
| 851 02 E 1412 P 50 | 23.00 | 11.70 | 22.25 | 25.30 |
| 851 02 E 1419 P 50 | 23.00 | 11.70 | 22.25 | 25.30 |
| 851 02 E 1626 P 50 | 24.61 | 11.70 | 25.42 | 28.45 |
| 851 02 E 1832 P 50 | 26.97 | 11.70 | 28.60 | 31.65 |
| 851 02 E 2041 P 50 | 29.36 | 14.35 | 31.77 | 34.80 |
| 851 02 E 2255 P 50 | 31.75 | 14.35 | 34.95 | 38.00 |
|
