Backshells
Standard backshells offer screw cable clamping. Two sizes of clamping bars are supplied to cater for various cable diameters.,IP65 backshells offer further protection with screw cable clamping and a neoprene sealing gland insert which is pre-split in decreasing circular gradients so that it may be cut to suit the cable diameter being used.
| Dimensions for Backshells (mm) |
| | Length | Clamp Dia. Max. | Dia. Min/Max. (neoprene gland) |
| IP65 | | | |
| Size 10 | 54 | 12 | 5//8 |
| Size 12 | 57 | 12.8 | 7//13 |
| Size 14 | 62 | 13 | 7//13 |
| Size 16 | 68 | 16 | 8//13.5 |
| Standard | | | |
| Size 10 | 40 | 8.7 | |
| Size 12 | 40 | 12.8 | |
| Size 14 | 46 | 13.8 | |
| Size 16 | 46 | 17 | |
