Schroff Novastar 系列 灰色 钢 坐地式 20U机架 19 英寸落地柜 16230007, 945 x 553 x 600mm

制造商零件编号:
16230007
制造商:
Schroff Schroff
库存编号:
754-0754
Schroff 16230007
声明:图片仅供参考,请以实物为准!

16230007产品详细信息

NOVASTAR Cabinet

The NOVASTAR cabinet is a slim-line and mobile enclosure designed for 19in. rack mount equipment, which combines the functionality required in the laboratory with the stylish design wanted in the studio. Built around a strong yet lightweight die-cast aluminium frame the cabinet offers a static load-carrying capacity of 200kg (400kg for the heavy duty version). It can be used without a door to allow unhindered access to the front of the mounted 19in. equipment or with a door which features an opening angle of 180 degrees. Quick release side panels offer further access and are recessed flush with the front and rear uprights to keep the overall cabinet width down to a space saving 553mm.

All uprights (front and rear) with 19in. cut-outs
Flush cladding parts
Ingress protection class IP20
3 cabinet depths (500, 600, 800 mm), cabinet width 553 mm
Static load-carrying capacity of 200 kg (9 U to 25 U) and 400 kg (34 U)
Colour combination: side panels RAL 7035 (light grey); frame, top cover RAL 7021 (black grey)

随附

1 x frame, diecast aluminium extrusion uprights with 19in.cut-outs (RAL 7021); 2 x 1mm steel side panels with twist-locking catch (RAL 7035); 1 x 1mm steel flush top cover (RAL 7021); 4 x feet; 1 x earthing kit.

16230007产品技术参数

  机架单元  20U
  类型  坐地式
  外部尺寸  945 x 553 x 600mm
  外部高度  945 mm
  外部宽度  553 mm
  外部深度  600mm
  系列  Novastar
  箱外壳材料  钢
  颜色  灰色
