10042137,219-6327,Nexans Draveil 10042137 250m 蓝色 恶劣环境导线, 0.22 mm2 横截面积, 24 AWG, 7/0.2 mm, 聚四氟乙烯绝缘, 250 V, 0.96mm外径, 镀银铜导体, 非屏蔽 ,Nexans Draveil
Applications: high-temperature wiring in electronic, aeronautic, avionic cabinets.
Sheath is UV resistant, as well as being resistant to common oils and acids.
| Core: | silver-plated copper |
| Insulator: | PTFE |
| Operating temperature: | C55 °C → +200 °C |
| constitution | ? external | |
| housing | (mm) | max. |
| 1 | 7 x 0.12 | 0.73 mm |
| 2 | 7 x 0.15 | 0.8 mm |
| 3 | 7 x 0.2 | 0.95 mm |
| 4 | 19 x 0.15 | 1.1 mm |
| 5 | 7 x 0.25 | 0.75 mm |
| 6 | 19 x 0.2 | 1.35 mm |
UTE C96-523
|
|
